Ports 1-24 support standard IEEE802.3af/at 30W output per PoE port 370W output of the total PoE Power
Forwarding Rates
35.7Mpps
Power Consumption
410W output the whole device
MAC Address List
8K
Four Modes
Standard: Default mode of the switch. In this mode, it works as an unmanaged switch; all ports can communicate with each other separately. Priority: In this mode, port 23,24,SFPand SFP2 serve as uplink ports, ports 1 – 8 serve as high priority port. All ports can communicate with each other separately. Extend: In this mode, data rate of ports 17 - 22 reduces to 10 Mbps, the maximum transmission distance can be 250 meters, and all ports can communicate with each other. VLAN: In this mode, ports 1 - 22 of the switch can communicate with port23,24,SFP1, SFP2 separately, but cannot communicate with each other. You can enable this mode to reduce broadcast storm and isolate DHCP broadcast.
