AI Instastream/ Instastream/ H.265 dual-stream video compression
Max 32 channels IP camera inputs, each channel up to 8MP; Max 128Mbps incoming bandwidth
Up to 8 channels video stream (analog channel) Perimeter Protection
Up to 16 channels video stream (analog channel) SMD Plus
Up to 2 channels video stream (analog channel) human face recognition
Support 1 SATA HDDs up to 16TB Each, 2 USB Ports
1 HDMI / 1 VGA simultaneous video output
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro
Processor
Industrial-grade processor
Operating System
Embedded LINUX
IP Camera Input
Up to 32 channels of IPC access 16 IP channels by default + 16 channels (analog channels are converted to IP channels) incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps *After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled
Gender; age group; glasses; expressions; face mask; beard
General Alarm
Motion detection; video loss; tampering; local alarm
Face Detection Performance of AI by DVR (Number of Channels)
2 channels (up to 12 face images/s each channel)
Bit Rate
32 Kbps–6144 Kbps Per Channel
Smart Phone
iPhone, iPad, Android Phone
Face Recognition Database Capacity
Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries & regions and state can be added to each face image
Anomaly Alarm
No disk; storage error; disk full; camera offline; IP conflict; MAC conflict
Face Recognition Performance of AI by DVR (Number of Channels)
2 Channels
Hard Disk
1 SATA port, up to 16TB capacity for each disk. The maximum HDD capacity varies with environment temperature.
Recording Mode
General, motion detection; intelligent; alarm; POS
Network Mode
Single-address mode
Backup Mode
USB Device/Network
Playback
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
Recording Playback
1/4/9/16
Ethernet
1 (10/100/1000 Mbps Ethernet port, RJ-45)
Interface Ports
2 (1 front USB 2.0 port, 1 rear USB 3.0 port), 1 RS485
