CP-UNR-4K5164-16EV2

16Ch. 4K AI Network Video Recorder with 16PoE Ports

Category: Network Video Recorder (NVR)

Sub Category: 16 Ch.

SKU: 35468

16 Channel IP video access
Instastream /H.265/Smart H.264+ /H.264/MJPEG
Max 320 Mbps incoming bandwidth
Up to 24MP resolution for live view and playback
1-channel fisheye dewarping (AI by NVR)
AI by Camera: Perimeter protection; face detection and recognition; SMD Plus; video metadata; ANPR; people counting; stereo analysis; crowd distribution; heat map
Support 4 SATA HDDs up to 10TB each, 3 USB Ports
2 HDMI/ 2 VGA simultaneous video output
Support Multi-brand network cameras
Support IPC UPnP, 16 PoE ports
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro

Processor	Industrial embedded micro-processor
Operating System	Embedded LINUX
User Interface	Web; local GUI
Video Output	HDMI1: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720 VGA1: 1920 × 1080; 1280 × 1024; 1280 × 720 HDMI2/VGA2: 1920 × 1080 VGA1/HMDI1 homologous output, VGA2/HDMI2 homologous output, and VGA1/HDMI1 and VGA2/HDMI2 supports heterogeneous output
IP Camera Input	16 channel
Performance	16 channel
Video Resolution	12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1.3MP, 720p, D1, and more
Video Recording	320 Mbps for access, 320 Mbps for storage and 320 Mbps for forwarding
Video Display Split	1st Screen: 1/4/8/9/16 ; 2nd screen: 1/4/8/9/16
Bandwidth Incoming	320 Mbps
Video Compression	Instastream/H.265/Smart H.264+/H.264/MJPEG
Channel	16
AI Search	Search for pictures by channel, time and event type
Face	6 attributes: Gender; age; glasses; expression; mouth mask; beard
Decoding Capability	16-channel@1080P (30 fps)
Alarm Linkage	Record; snapshot; IPC external alarm output; buzzer; log; preset; email
Video Loss	Supports
General Alarm	Motion detection; privacy masking; video loss; local alarm; PIR alarm; IPC alarm
Smart Phone	iPhone, iPad, Android Phone
Anomaly Alarm	Camera offline; storage error; full storage; IP conflict; MAC conflict; login lock; network security anomaly
Audio Compression	PCM; G.711A; G.711U; G.726
Audio Input	1 channel, RCA connector
Audio Output	2 channels, RCA connector, which supports voice intercom output
Hard Disk	4 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
Alarm Input	16 Channel
Alarm Output	6 Channel
Recording Mode	Manual; schedule (general; MD; alarm; MD & alarm; intelligent; POS)
Backup Mode	USB device
Playback Function	Play; pause; stop; fast forward; fast backward; rewind; play by frame, Full screen; backup (cut/file) ; partially enlarge; audio on/of
Ethernet	1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet port , 1 eSATA Port
Interface Ports	3 USB Ports (1 front USB 2.0 port, 2 rear USB 3.0 ports ), 1 RS232, 1 RS485
PoE Ports	16 ports (IEEE802.3af/at) ; 1-8 ports support ePoE & EoC
Protocol	HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search; InstaOn; ONVIF (profile T/S/G); CGI; SDK
Power Supply	Single, 100V–240V AC, 50 Hz–60 Hz
Power Consumption	NVR: < 17.5W (without HDD) ; PoE: Max 25.5W for single port
Working Temp	-10°C to +55°C (+14°F to +131°F)
Dimension	440 mm × 412.2 mm × 76.0 mm
Operating Altitude	3000m
Weight	4.65kg (without HDD)
